The Cadex Dovetail Low Profile NVG Mount offers improvements over existing mounts in several key areas:
Force-to-overcome to stow eliminates chances of neck injuries (If the NVG is bumped or impacted the Low Profile Flip Up Mount will fold and lock in upright position)
Push-button to deploy eliminates accidental deployments under harsh bumps
User-Adjustable dovetail shoe to fit off-spec devices
Optional breakaway feature gives users the option to allow the mount to break-free from the NVG shroud under impact
Increased overall fore/aft rail travel places NVGs substantially closer to the user's eye and farther out to accommodate for gas masks and other eyewear compared to industry mounts such as the Wilcox G24 (~2 inches of travel)
Steel-reinforced tilt adjustment plate eliminates common failure point
Intuitive NVG device release lever allows rapid removal of NVG device but is shielded by fore/aft adjustment rails
Ergonomic “one touch” spring-loaded height adjustment allows operator to adjust height with one hand.
Low profile follows helmet contour when folded.
New generation mounts include a hole for weight reduction and wire organization
Six position adjustable mounting plate fits numerous facial profiles and helmet mounting systems.
Specifications
Dimensions
3.83″ x 2.88″ x 3.06″
9.73 x 7.33 x 7.77 cm
Weight
0.368 lbs
165 grams
Material
CNC 7075-T6 Aluminum
Breakaway
Optional (Both Breakaway and Non-Breakaway Available)
