Custom Built Nocturn Industries Daisho Complete Binocular NVG

Custom Built Nocturn Industries Daisho Complete Binocular NVG

Regular price $6,746.00 USD
Regular price Sale price $6,746.00 USD
Sale Sold out

The Daisho Complete Binocular NVG is a three-part system consisting of two Tanto monoculars, and a Daisho bridge. The Daisho bridge unifies power into a single CR123A power supply and adds individual auto-pod shut-off when they are rolled out of view.

Users can quickly dismount the Tanto monoculars for individual use with individual CR123A power with a J-arm (not included) or re-attach them in minutes (tools required).

To remove the Tanto monoculars from the Daisho bridge is simple:



A full video from Nocturn Industries can be found HERE.

  1. Remove 4x Torx screws from the bridge and keep the IPD plates and screws
  2. Swing the rear latch open
  3. Slide the Tantos off of the Daisho power rods
  4. Re-attach the battery caps onto each Tanto


Specifications
Material Polymer with aluminum dovetail and pod retention tabs on rear
Tube Type 18mm MX-10160 tubes
Figure of Merit (FOM) SNR x LP/mm

NNVT NVT4-AG (1600+ FOM)
Photonis Echo (1600-2000FOM)
Photonis Echo+ (2000+FOM)

Weight

538g with Milspec standard optics and a battery

Power Supply CR123 onboard OR external battery pack via LEMO port (LEMO port version is special-order only)
Runtime 16+ hours
Lenses Noctis Technologies (formerly Carson Industries) US Milspec
Field of View 40º
Interpupillary Adjustment Range 51-73mm
Diopter Adjustable +2 to -6
Submersion and Dust Rating Up to 20 metres
Mount Style Built in dovetail mount
Onboard IR Illuminator No





INCLUDED

  • 2x Nocturn Industries Tanto Monoculars
  • 1x Daisho Bridge with Hardware
  • Cold Harbour Pro Case
  • Hoffman test report and tube spec sheet
  • 12 month warranty
  • Manufactures lifetime warranty on housings and bridge
